WEB Catalog

Product Information ?  WEB Catalog  ? Air Cylinders  ? Environment Resistant Cylinders

Environment Resistant Cylinders

Stainless Steel Cylinder / Non-adjustable Air Cushion Type HF2A-CG5

    ?Equipment for the Food Manufacturing Industry
    ?All stainless steel specifications (External parts: Stainless steel 304)
    ?4 times better durability in environments where it may come into
    　contact with water droplets
    ?Non-adjustable air cushion
    ?Mounting interchangeability between the stainless steel cylinder,
    　CG5-S series
  • 2D/3D CAD

    The new SMC CAD SYSTEM, CADENAS, allows you to output 2D/3D CAD data with full part numbers in various data formats. Responses to part number selection has been greatly improved with the newly developed system.

    Click here for 2D/3D CAD
SeriesTypeBore size
HF2A-CG5Air cushion20mm, 25mm, 32mm, 40mm

Features

All stainless steel specifications (External parts: Stainless steel 304)



4 times better durability in environments where it may come into contact with water droplets

Water-resistant construction by seals (Scraper, Tube gasket: FKM)
Scraper: Blue FKM
Using materials compliant with the US FDA.
The scraper material complies with regulation (EC) No. 1935/2004 for food contact applications.
Grease used: NSF H1 grease

? The durability test is conducted under SMC's test conditions.

Equipment for the Food Manufacturing Industry

Non-adjustable air cushion

?Smooth stopping at the end surface is realized resulting in reduced noise and impact at end of stroke. (Compared with the rubber bumper)
?Air cushion adjustment is not required.



Mounting interchangeability between the stainless steel cylinder, CG5-S series



Clean design

Mounting Brackets

Equipment for the Food Manufacturing Industry

Related Products
